Product Details:
Payment & Shipping Terms:
|
Material:
Pitch:2.54mm
Poles: 2P-30P can assembly any poles
Screw: M2.5 Steel Zinc plated
Contact: Phosphor bronze Ni plated
Wire cage: Brass Ni plated or steel zinc plated.
Housing: PA66 UL 94-0
Electrical:
Rated voltage: 150V
Rated current: 6A
With standing voltage: AC1250V/1min
Wire range: 24-12 AWG
Mechanical:
Temperature range: -40℃ ~ +105℃
Max soldering: +250℃ for 5sec.
Torque: 0.1Nm(0.88 lb in)
Strip length: 5-6mm
