Product Details:
Payment & Shipping Terms:
|
| Highlight: | terminal block,Plug blocks,connectors |
||
|---|---|---|---|
Material:
Pitch:5.0mm
Poles: 2P 3P, can assembly any poles
Screw: M2.5 Steel Zinc plated
Contact: Phosphor bronze Ni plated
Wire cage: Brass Ni plated or steel zinc plated.
Housing: PA66 UL 94-0
Electrical:
Rated voltage: 300V
Rated current: 15A
With standing voltage: AC2000V/1min
Wire range: 22-12 AWG
Mechanical:
Temperature range: -30℃ ~ +105℃
Max soldering: +250℃ for 5sec.
Torque: 0.4Nm(3.5 lb in)
Strip length: 4.5-5mm
